Introducing the SH1200UR "TRAFFIC UPS^TM" from Sense Products.
Designed and manufactured for the traffic industry.

Compatible with traffic signals using amber incandescent lamps

One of the many advancements made in today's traffic intersection control technology has been the emergence of the LED traffic signal. This rapidly growing technology affords its users energy efficiency, reliability and longer life compared to the incandescent technology it is replacing. As a result, power failure interruptions need not be a concern anymore.

The SH1200UR offers the most advanced technology to provide the ultimate in reliability, safety and system performance for LED traffic intersections. In the event utility power fails, the SH1200UR automatically detects the failure and instantly becomes a quality power source utilizing true sine wave technology that is identical or better than your utility. All this, without interruption to your traffic control system.

The fully programmable front display panel enables the user to monitor and control important data and alarms without the use of computer hardware. Additionally, the SH1200UR offers, as standard, the most advanced transient voltage surge suppression available. Furthermore, our non-MOV system eliminates failures and fires within the "TVSS". The SH1200UR does not shunt disturbance current to the ground system, which can disturb your critical application.

At the heart of any battery back-up power system is, of course, the reliability of the battery, as it is the most likely component to deteriorate and fail over time. The SH1200UR utilizes parallel technology for redundant battery reliability, which enhances our system's reliability in the event of a battery failure as our system can still provide power to the UPS. Unlike other systems, the SH1200UR utilizes a parallel connected battery system offering multi-level redundancy, insuring system operation.



SH1200UR TRAFFIC UPS^TM Specifications

Input

	VOLTAGE: 85 VAC to 135 VAC
	FREQUENCY: 40 to 70 Hz
	POWER FACTOR: >= 0.98

Input Protection

	Protects UPS and Critical Load at all times
	Series Mode Technology does not Shunt Disturbance to Ground
	Does not use MOVs
	Meets current U.S. Government guidelines: Grade A Endurance, Class 1 Performance,
	Mode 1 Application, Endurance C62.41-1991 (Formerly IEEE 587) Category B3 (C 1) Pulse
	EMI/RFI Filter Response Bi-Directional, Wave Tracking

Output Rating: 800 Watts @ 74°C

	VOLTAGE: 117 VAC ±2%
	FREQUENCY: 60 Hz ±0.05%
	LOAD POWER FACTOR RANGE: 0 to 1 Inductive, Capacitive or Non-Linear Load to 2kVA
	CREST FACTOR: 3.2 to 1 (100% LOAD)
	TOTAL HARMONIC DISTORTION: <= 2%
	OVERLOAD: 110% Continuous @ 60°C (140°F)                 200% for 15 Min. @ 60°C (MOT)
	EFFICIENCY: 91%

Controls and Indicators

	LCD Front Panel, Back-lit, Programmable Display
	True Battery Temperature Compensation via Battery Temperature Probe, Programmable
	Battery Recharge Regime and Rates, Programmable
	Input Circuit Breaker
	Output Circuit Breaker
	UPS Enable Switch
	Serial Port
	Programmable alarm outputs

FLASHER CIRCUIT: Range 0.1 Minutes to 10 Hours Adjustable Two (2) Sets of Contacts Battery

Battery

	TYPE: Gelled or Absorded Glass Mat, Non-Spillable, Valve Regulated
	Parallel Technology for Redundant Battery Reliability
	TYPICAL RECHARGE TIME: 8 Hours or Less
	Programmable Battery Charge Algorithm and Regime

Mechanical

	Advanced Heat Sink Technology
	Intelligent Air Flow
	Locking Connectors
	WEIGHT: 36 lbs.
	DIMENSIONS: 19"w x 14"d x 6"h

Environmental

	OPERATING TEMPERATURE: -40°C to 74°C
	HUMIDITY: 5% to 95% Relative Humidity, Non-Condensing
